DESCRIPTION
- 세개의 오프셋으로 구성된 버터플라이 밸브.
APPLICATION
- 사용환경이 고온이거나 기포 차단이 필요한 까다로운 공정에 사용.
APPLICATION
- 금속 씰링 및 토크 시팅을 사용하여 유체 누출이 없음.
- 비마찰 특성으로 내구성이 우수함.
- 작동 토크가 낮아 자동화가 용이함.
TYPE | STAINLESS STEEL PLUMBING VALVE | SANITARY VALVE | VACUUM VALVE |
SIZE | 1-1/2”(40A) ~120”(3000A) | 0.5S ~ 4.0S | NW25~160 |
BODY | SCS16(CF3M), SCS14(CF8M), SCS13(CF8), FCD, FC | SCS313(CF8), SCS14(CF8M) | SCS13(CF8) |
SEAT | EPDM, NBR, PTFE, RTFE, VITON | EPDM, NBR, PTFE, RTFE, VITON | SILICONE, EPDM |
END CONNECTION | WAFER, LUG, FLANGED | T-CLAMP ENDS | NW, ISO |
OPERATION | MANUAL, AUTOMATIC(PNEUMATIC, ELECTRIC) | ||
